KDSBuilding’s solid wood hand crank windows blend traditional craftsmanship with modern engineering. Each frame is crafted from high-quality hardwood, ensuring natural beauty and long-lasting durability. The hand crank mechanism offers smooth, effortless operation—ideal for hard-to-reach areas while maintaining a classic architectural look. Our wood windows are treated for weather resistance, preventing warping, moisture damage, and insect intrusion. With energy-efficient glazing and tight sealing, they deliver excellent insulation against heat and noise. Whether for heritage restoration or luxury homes, these solid wood crank windows enhance interiors with warmth and sophistication. Combining artistry and technology, KDSBuilding offers windows that truly stand the test of time.
series: Wooden
opening style: hand crank Casement
Glass: 5 mm+9 A+5 mm double tempered clear glass
Color: wooden color
Certification: CE, AS 2047 , CE
Item NO.:
KDS-W-W-HC-001Payment:
DPProduct Origin:
ChinaColor:
CUSTOMIZEDShipping Port:
ChinaLead Time:
15-30daysTechnical Speicification
| Classify | Technical parameter | Other Options | |
| Profile system |
|
|
|
| Material | wood | solid wood, mdf | |
| Structure | composite wood | plywood, mdf | |
| thickness | 45 mm | 50 mm, 55 mm | |
| Finish | wood finish |
Laminated wood grain, golden oak |
|
| Glazing system |
|
|
|
| Glass type | 5mm+9A+5mm | Single Glass, Triple Glass | |
| Glass color | Clear | Tinted, blue, green, grey etc | |
| Gas Filling | Argon | Air, Argon,Krypton | |
| Special function | Tempered |
Low-e, laminated, bullet proof,
|
|
| Hardware&Operation |
|
|
|
| Hardware Brand | Chinese top brand Hardware | Roto, Siegenia, Kinlong | |
| Main Hardware | lock,D-type handle, lock, roller | Heavy-duty roller set | |
| Locking system | multi point lock |
Multi-point lock, crescent lock |
|
| Sealing | EPDM | Silicone, PVC gasket | |
| Performance Ratings |
|
|
|
| U-Factor |
≤ 0.3 |
≤ 0.25 with triple glass | |
| SHGC |
SHGC ≤ 0.23 |
Low-E for better SHGC |
|
| Wind load |
≥ 3000 pa |
≥ 4500 Pa | |
| Water Tightness |
≥ 450 pa |
≥ 500 Pa | |
| Air Tightness |
≤ 0.4 m3(㎡.h) |
≤ 0.3 m³/(m²·h) | |
| Manufacturing Service |
|
|
|
| Size Range | Sash width: 500–1500 mm Sash height: 500–1800 mm | Customized size | |
| Warranty | 5 Year | except damage caused by human | |
| Certification | CE, NFRC, AS2047, TITLE 24, AAMA |
Detail
Certification
Application
FAQ
Wood Glass Windows And Doors
Q1:What are the types of your solid wood window and door profiles?
Wood Type:Russian Larch,American Oak,Canadian Hemlock,Teak,Pine,etc.Wood Color:Nature Solid Wood Grain + Painting Yellow,Brown,Red,White,etc.
Q2:What are the types of your window and door glasses?
1.Type:Tempered,Insulated,Laminated,Low-e,Float,Reflective,Bullet-proof,etc. 2.Layer:Single / Double / Triplex Glasses for reducing summer heat load and winter heat loss.3.Color:Clear (Transparent),Frosted,Grey,Blown,Green,Blue,etc.
4.Thickness:4mm,5mm,6mm,8mm,10mm,12mm,15mm,19mm.5.Insulated Glass Spacer:6A,9A,12A,15A,16A.Standard Insulated Glass: 5mm+9A/12A+5mm,6mm+9A/12A+6mm with argon gas filled inside.Standard Laminated Glass:5mm+0.38PVB+5mm,5mm+0.76PVB+5mm.6.Quality Standard:European standard CE,Australian standard AS2208,Chinese standard CCC.
Q3:What are the types of your window and door accessories?
1.Brand:German, American, Australian, Chinese Top Brands,etc.2.Accessories:handles,hinges,locks,rollers,linkage devices,etc.
Q4:What are the package types of your windows and doors?
1.Steps:(1)Use air blow gun and thinner to clean products surface.(2)Use Air bubble film / PE film / EPE foam to wrap products against sea water corrosion.(3)Use craft paper / corrugated paper to protect product four corners.(4)Load FCL Packing products into container directly.(Note:Use container lashing belt to fasten FCL packing irregular goods.)(5)Load LCL Packing products into plywood cases / iron pallets with packing belt,then into container.(FCL:full container load;LCL:less than a container load)2.List:Pallet list for each pallet of a large amount purchase,saving time for you to sort out each window or door.
Q5:What is delivery time of your windows and doors?
Our goods are usually shipped by 20-50 workdays after payment.Different goods quantity means different delivery time.Please send your detailed windows and doors schedule to us,then we will confirm the exact delivery time for you.
Q6:How can we install your windows and doors at our building side?
We can offer the detailed windows and doors installation drawing for you.We also have our professional installation team in Australia and Philippines who can help you if you need.
Q7:This is my first time to import windows and doors, how should I do?
We have 20 years exporting experience.In order to save both your time and money,we can serve you as follows.1.We can direct a series of importing affairs for you.2.We can supply you one-stop purchase service of various building materials if you need.
